Utilized in different applications, leaf chains are regulated by ANSI. They could be utilized for forklift masts, as balancers between heads and counterweight in some machine gadgets, and for low-speed pulling and tension linkage. Leaf chains are occasionally even referred to as Balance Chains.
Construction and Features
Leaf chains are steel chains using a simple link plate and pin construction. The chain number refers to the pitch and the lacing of the links. The chains have particular features like for instance high tensile strength per section area, that enables the design of smaller machines. There are A- and B- kind chains in this particular series and both the AL6 and BL6 Series comprise the same pitch as RS60. Finally, these chains cannot be driven with sprockets.
Handling and Selection
In roller chains, the link plates maintain a higher fatigue resistance because of the compressive stress of press fits, yet the leaf chain just has two outer press fit plates. On the leaf chain, the maximum permissible tension is low and the tensile strength is high. When handling leaf chains it is vital to consult the manufacturer's manual in order to ensure the safety factor is outlined and use safety guards always. It is a great idea to apply extreme caution and use extra safety measures in functions where the consequences of chain failure are severe.
Utilizing a lot more plates in the lacing leads to the higher tensile strength. In view of the fact that this does not enhance the most acceptable tension directly, the number of plates utilized can be restricted. The chains need regular lubrication for the reason that the pins link directly on the plates, producing an extremely high bearing pressure. Using a SAE 30 or 40 machine oil is often advised for most applications. If the chain is cycled more than 1000 times every day or if the chain speed is more than 30m for every minute, it will wear extremely rapidly, even with continuous lubrication. So, in either of these conditions utilizing RS Roller Chains would be more suitable.
The AL-type of chains should only be utilized under certain situations like for instance if wear is really not a huge problem, when there are no shock loads, the number of cycles does not go beyond a hundred each day. The BL-type will be better suited under other conditions.
The stress load in parts will become higher if a chain with a lower safety factor is selected. If the chain is also utilized amongst corrosive conditions, it can easily fatigue and break very fast. Doing frequent maintenance is really essential when operating under these kinds of situations.
The inner link or outer link type of end link on the chain will determine the shape of the clevis. Clevis connectors or also known as Clevis pins are constructed by manufacturers, but the user normally provides the clevis. A wrongly constructed clevis can decrease the working life of the chain. The strands should be finished to length by the producer. Refer to the ANSI standard or call the maker.
