Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid installed on it. When current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion with the starter ring gear which is seen on the flywheel of the engine.
As soon as the starter motor starts to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid consists of a key operated switch that opens the spring assembly so as to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this particular method via the pinion to the flywheel ring gear. The pinion remains engaged, for instance for the reason that the operator did not release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.
The actions discussed above would prevent the engine from driving the starter. This important step stops the starter from spinning really fast that it could fly apart. Unless modifications were done, the sprag clutch arrangement will stop utilizing the starter as a generator if it was used in the hybrid scheme discussed earlier. Usually a standard starter motor is designed for intermittent use that will preclude it being used as a generator.
Thus, the electrical components are meant to work for roughly less than thirty seconds to avoid overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical components are designed to save weight and cost. This is really the reason most owner's handbooks utilized for vehicles recommend the driver to stop for at least 10 seconds right after each and every ten or fifteen seconds of cranking the engine, if trying to start an engine that does not turn over instantly.
The overrunning-clutch pinion was introduced onto the marked in the early 1960's. Before the 1960's, a Bendix drive was used. This particular drive system operates on a helically cut driveshaft that has a starter drive pinion placed on it. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, therefore engaging with the ring gear. Once the engine starts, the backdrive caused from the ring gear enables the pinion to go beyond the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design which was developed and launched in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights in the body of the drive unit. This was better since the typical Bendix drive used in order to disengage from the ring as soon as the engine fired, even if it did not stay functioning.
The drive unit if force forward by inertia on the helical shaft once the starter motor is engaged and starts turning. After that the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement could be avoided prior to a successful engine start.
